Banner Engineering DX80G9M6S-P2 is a Sure Cross® DX80 Performance-series industrial wireless gateway (900 MHz FHSS) with built-in I/O and an RS-485 Modbus RTU host interface. It provides 4 selectable discrete inputs (PNP/NPN), 2 universal analog inputs (0–20 mA default or 0–10 V configurable), 4 PNP sourcing discrete outputs, and 2 analog current outputs (0–20 mA). The unit is powered from 10–30 V DC, is housed in a rugged IP67/NEMA 6 enclosure for harsh environments, and supports external antenna connectivity for long-range industrial telemetry and remote I/O networking.
Phoenix RAD-2400-IFS Wireless Module
₹54,163.64 – ₹59,681.62
StarTech ICUSB2321F USB to RS232 Converter
₹4,556.68 – ₹4,977.18
Banner DX80G9M6S Gateway
| Brand | : | Banner Engineering |
| Category | : | wireless remote I/O |
| Model Number | : | DX80G9M6S-P2 |
| Manufacturer Part Number | : | DX80G9M6S-P2 |
Dispatch within 10 days
₹67,110.48 – ₹69,275.71
0
People watching this product now!
Description
Specification
I/O & Signal
| Number of Digital Inputs (DI) | 4 |
|---|---|
| Number of Digital Outputs (DO) | 4 |
Communication
| Supported Protocols / Ports | Modbus RTU (RS-485), Sure Cross® wireless (900 MHz FHSS, ISM) |
|---|
Power & Protection
| Power Supply Requirement | 10–30 V DC |
|---|
