MS4-LOE-1/4-U is a Festo proportional standard mist lubricator in the MS series for compressed air preparation. The official datasheet specifies G1/4 ports, 1 to 12 bar operating pressure, 40 l/min minimum flow for lubricator function, 2200 l/min standard nominal flow, and an ambient and media temperature range of -10 °C to 60 °C. It is designed for compressed air to ISO 8573-1:2010 [7:4:4] and inert gases, with an integrated metal bowl, 36 cm³ maximum oil capacity, and a die-cast aluminium housing and bowl.
Festo MS4-LFM-1/4 Micro Filter
₹7,102.85 – ₹12,225.34
SMC AL40-F04 Lubricator
₹5,356.92 – ₹8,023.00
Description
Specification
Communication
| Connector Type | G1/4 pneumatic connection |
|---|
Environmental
| Operating Temperature Range | -10 °C to 60 °C |
|---|
Safety / compliance
| Certifications / Standards | RoHS-compliant, LABS (PWIS) conformity VDMA24364-B1/B2-L |
|---|
Commercial Basics
| Variant / Series | MS4 / MS series |
|---|
