The Fluke 709H is a precision mA loop calibrator with HART communications and diagnostics for servicing HART-enabled transmitters. It provides mA source, simulate, read, read with loop power, and voltage read functions, includes a built-in selectable 250 Ω resistor for HART communication, logs up to 9800 records or 99 sessions, and is designed as a compact rugged handheld tool with a quick-set rotary encoder knob.
Additel ADT209 Loop Calibrator
₹10,099.21 – ₹1,05,330.82
Beamex MC6 Field Calibrator
₹13,29,418.09 – ₹19,98,775.45
Fluke 709H Loop Calibrator
| Brand | : | Fluke |
| Category | : | Loop calibrators (mA / voltage simulators) |
| Model Number | : | 709H |
| Manufacturer Part Number | : | 709H |
Dispatch within 10 days
₹1,77,006.91 – ₹2,28,873.79
0
People watching this product now!
Description
Specification
Electrical Input/Output
| Output Voltage | 24 V DC @ 20 mA |
|---|---|
| Output Current | 0 to 24 mA |
Communication
| Supported Protocols / Ports | HART |
|---|
Environmental
| Operating Temperature Range | -10 °C to 55 °C |
|---|
