Gems Sensors 164520 (LS-7 Series) is a compact float-type liquid level switch for simple ON/OFF level detection in tanks. It is a passive SPST dry-contact switch (no supply required) with a 20 VA contact rating, and it can be set as NO or NC by rotating the float 180°. Built with polypropylene stem/float and supplied with a Buna-N gasket and 24-inch lead wires, it’s suitable for many water-compatible applications and operates over a wide −40 to +107.2 °C temperature range, making it a practical, reliable choice for panel/tank level alarm or pump control interlocks.
Siemens 3UG4501-2AW30 Level Monitoring Relay
₹10,005.56 – ₹30,143.12
WIKA RLS-1000 Float Level Switch
₹4,667.13 – ₹49,559.00
Description
Specification
I/O & Signal
| Number of Digital Outputs (DO) | 1 (SPST switch) |
|---|
Environmental
| Operating Temperature Range | -40 °C to +107.2 °C (-40 °F to +225 °F) |
|---|
Physical
| Enclosure / Material | Polypropylene (stem/float), TPE lead wire jacket |
|---|---|
| Dimensions (L×W×H) | Overall length 97.5 mm, stem length 69.8 mm, hex 16 mm |
Contact us for Data Sheet
