SICK KTS-WB41141142ZZZZ (KTS Core series) is a compact contrast sensor for reliable registration/mark detection at short range (≤13 mm). It uses an RGB LED light source and 2-point teach-in (ET input) for quick setup, with fast 20 µs response time and up to 25 kHz switching for high-speed packaging/printing lines. It provides a push-pull (PNP/NPN) light/dark switching output, operates on 10.8…28.8 V DC, and comes in an IP67-rated industrial housing.
Autonics BC15-LDT-C Color Mark Sensor
₹13,891.00 – ₹29,826.00
Keyence CZ-H35S Reflective Sensor
₹22,639.49 – ₹24,415.38
SICK KTS Contrast Sensor
| Brand | : | SICK |
| Category | : | Color / mark detection sensors |
| Model Number | : | KTS-WB41141142ZZZZ |
| Manufacturer Part Number | : | KTS-WB41141142ZZZZ |
Dispatch within 10 days
₹5,800.00 – ₹51,218.84
0
People watching this product now!
Description
Specification
Communication
| Connector Type | M12 (male), 4-pin |
|---|
Power & Protection
| Power Supply Requirement | 10.8–28.8 V DC |
|---|
Environmental
| Operating Temperature Range | -20 °C to +60 °C |
|---|
Physical
| Dimensions (L×W×H) | 26 × 62 × 47.5 mm |
|---|
