Siemens 3VA1110-4ED32-0AA0 is a SENTRON 3VA1 3-pole molded case circuit breaker for line protection, frame size 160, with class S breaking capacity up to 36 kA at 415 V. It uses a TM210 thermomagnetic trip unit with fixed 100 A overload protection and fixed short-circuit protection at 10 × In, supports up to 690 V AC / 500 V DC, and has IP40 front protection.
Schneider C10F3TM100 100A MCCB
₹8,382.40 – ₹10,870.00
ABB XT1B160 MCCB
₹11,010.00 – ₹35,913.02
Description
Specification
Electrical Input/Output
| Output Current | 100 A |
|---|
Power & Protection
| Protection Features | Overload protection Ir=100 A fixed, short-circuit protection Ii=10 x In, front IP40 |
|---|
Environmental
| Operating Temperature Range | -25 °C to +70 °C |
|---|
Safety / compliance
| Voltage Class | Ui 800 V, Ue 690 V AC / 500 V DC |
|---|
Contact us for Data Sheet
